Main parameter

Image Sensor

1/1.8” SONY Starlight custom sensor

Signal Type

Network signal

Resolution

1920*1080

Minimal Illumination

Color&BW 0.00001Lux@F1.2

Main Code Stream

1920*1080，1-25(30)Frames/Sec 1280*720，1-25(30)Frames/Sec

Video Compression Code Stream

32Kbps-16Mbps，Continuously adjustable, support CBR/VBR

Video Encode

H264，Baseline/Main Profile/High Profile Code；H.265 Main Profile Code

Shell Material

Optional stainless steel/Titanium alloy/Industrial plastic

Waterproof Level

0-300 meters(The deepest can be customized 6000 meters)

Voltage Supply

12VDC, 24VDC, 36VDC (Optional)

Working Temperature

-30℃～+60℃

Size

Φ65*170mm(Not including parts 34mm)

Customization

Depth(The deepest can do 6000M)

Sensor (Temperature、Pressure...)

Control display terminal
