45mm Underwater AHD Camera
45mm Underwater AHD Camera
45mm Underwater AHD Camera
45mm Underwater AHD Camera
45mm Underwater AHD Camera
45mm Underwater AHD Camera
GLF-UDC-D45
Product Profile
  • Ultra Low Light, Built-in Light Source, Ultra HD 1200W pixels
  • 2 million coaxial HD CMOS
  • Continuous horizontal rotation 360°，Vertical direction -5°-90°,no monitoring blind area
  • 6 high-brightness 0.5W white LEDS built-in lights, support 10-level micro-variable dimming
  • Products can be customized according to different situations
Features:
1080P HD
360° Rotation
100m waterproof
Adjustable LEDs
Contact Us
KEY FEATURES
  • 1080P HD
    1080P HD
  • Rotation
    Rotation
  • 100M
    100M
  • LEDs
    LEDs

Main Parameters

Image Sensor

2M coaxial HD COMS/1080p

Signal Type

Coaxial HD

Pixel

2MP

System

PAL/NTSC optional

Minimal Illumination

0.01 lux at F1.2 5600°K

Video Output

1V‐75 ohms AHD/CVBS,video signal (Anti-interference technology)

Rotation Range

PAN 360° Rotation, TILT 180°

Material

Stainless steel/Titanium alloy

Waterproof Level

0-100 meters

Power Supply

24VDC

Operating Temperature

-20℃ ~ +60℃

Size

Φ45*105 (Not including parts 34mm connector)

Customization

Depth

Sensor （Temperature、Pressure...）

Control display screen
